Sharp maps released from space shuttle mission
Posted: July 12, 2002

People around the world will soon get to see their home planet in an entirely new way, as NASA extends the release of detailed topographical maps collected during the 2000 Shuttle Radar Topography Mission beyond U.S. borders to the rest of the globe.

Manila Bay
These two images show exactly the same area, Manila Bay and nearby volcanoes on Luzon Island in the Philippines. The image on the left was created using the best global topographic data set previously available, the U.S. Geological Survey's GTOPO30. In contrast, the much more detailed image on the right was generated with data from the Shuttle Radar Topography Mission. The city of Manila is on the eastern shore of Manila Bay at the right edge of the image. The large central plain to the north of the bay, irrigated by the Panpanga and Agno rivers, is the most important agricultural region in the Philippines. The Bataan Peninsula and volcanic Mt. Bataan at lower center along with the small island of Corregidor near the bottom edge became famous when the Allied forces made their last stand there during World War II. Dominating the upper left of the scene is 1,600-meter-high Mt. Pinatubo, whose violent eruption on June 15, 1991, wrought widespread destruction on Luzon as well as injecting dust and gas into the atmosphere, which lowered global average temperatures for over a year. Credit: NASA/JPL/NIMA
NASA and the National Imagery and Mapping Agency (NIMA), partners in the shuttle mapping mission, agreed this week on a policy to provide 90-meter (295-foot) resolution digital- elevation mission data from sites outside the United States to qualified researchers. Selected data will simultaneously become available to the public. The two agencies also this week made public the mission's research-quality 30-meter (98- foot) resolution topographic data for the entire continental United States.

National Imagery and Mapping Agency Director James R. Clapper and NASA Administrator Sean O'Keefe signed the agreement this week at NASA Headquarters, Washington.

"Americans take for granted the quality of U.S. topographic maps, but for millions of people around the world, particularly those in the frequently cloud-covered equatorial regions, the elevation maps created with these data will be ten times more precise than the best available today," Administrator O'Keefe said. "That kind of improvement will lead to significant advancements in aviation safety and mitigation of natural hazards, and to smarter and more sustainable urban development, to name but a few applications."

"SRTM is one of the best geospatial collection tools not only in NIMA's experience, but in the history of mapping," said Clapper. "This mission helps meet our strategic goal of providing the best geospatial information to our customers.

"For commercial and civil applications, the improved data is likely to find many uses that will save lives and enhance economic development around the world. Our team effort with NASA is a shining example of how we can adapt available technology, in partnership with other federal agencies and civilian contractors, to get world-class information."

The practical benefits of space-based synthetic-aperture radar data, which can see through clouds and provide researchers with terrain data of exceptional quality, can be applied to uses as diverse as flood plain mapping and location of cellular telephone towers in mountainous regions.

"Take aviation safety, for example. Today, more than 60 percent of fatal aviation accidents involve controlled flight into terrain due to poor visibility. By combining Shuttle Radar Topography Mission and Global Positioning System data, we can create a global terrain database and high-fidelity cockpit visualizations that will virtually display surrounding terrain, even in conditions of darkness or clouds. NASA is working with the Federal Aviation Administration, the aviation industry and the Department of Defense to develop these technologies, which promise to significantly reduce the aviation accident rate worldwide," said Dr. Ghassem Asrar, Associate Administrator for Earth Science, NASA Headquarters.

These two images show exactly the same area, Lake Balbina near Manaus, Brazil. The image on the left was created using the best global topographic data set previously available, the U.S. Geological Survey's GTOPO30. In contrast, the much more detailed image on the right was generated with data from the Shuttle Radar Topography Mission. Lake Balbina is a man-made reservoir created to supply hydroelectric power to the city of Manaus, located 125 kilometers to the south. The reservoir is located on the Uatuma River and drains a 19,100-square-kilometer basin of mostly upland topography where the relief extends from 30 meters to 200 meters in elevation. Credit: NASA/JPL/NIMA
Shuttle Radar Topography Mission data are being processed at NASA's Jet Propulsion Laboratory (JPL), Pasadena, Calif., into research-quality digital-elevation models one continent at a time. When each continent is completed, the data will be sent to NIMA for additional finishing and then to the U.S. Geological Survey's Earth Resources Observation Systems Data Center in Sioux Falls, S.D., for final archiving and distribution.

NASA is processing mission data for research purposes in response to requests from NASA principal investigators and other qualified scientists. Under the terms of the new agreement, researchers will submit their requests for international topography data to NASA/JPL. The requests will be reviewed by NASA and NIMA, and the data will be released either for use by the approved researchers or for broad public access. Decisions on how data will be released will be made on a case-by-case basis.

NASA began processing mission data in April 2002 and expects to have all mission data processed and delivered to NIMA by the end of this year. All international 90-meter (295-foot) resolution data is expected to be available to the public no later than two years after JPL makes its final data delivery.

Still in discussion is a release policy for international 30- meter (98-foot) resolution measurements. However, at the National Imagery and Mapping Agency's discretion, some 30- meter resolution international data may be made available in special situations in which the information can help protect life and property, such as during volcanic eruptions and floods; NASA, however, will have access to such data for its sponsored scientific research.

The Shuttle Radar Topography Mission (Feb. 11-22, 2000) made 3-D measurements of more than 80 percent of Earth's landmass between 60 degrees north and 56 degrees south of the equator, areas home to nearly 95 percent of the world's population.

An artist's concept of Endeavour during it's mapping mission. Credit: NASA/JPL
