Volcanic Io erupts
NASA/JPL PHOTO RELEASE
Posted: March 4, 2001

This pair of images taken by NASA's Galileo spacecraft captures a dynamic eruption at Tvashtar Catena, a chain of volcanic bowls on Jupiter's moon Io. They show a change in the location of hot lava over a period of a few months in 1999 and early 2000.

Tvashtar Catena
Eruption at Tvashtar Catena on Io. Photo: NASA/JPL

The image on the left uses data obtained on Nov. 26 and July 3, 1999, at resolutions of 183 meters (600 feet) and 1.3 kilometers (0.8 miles) per pixel, respectively. The red and yellow lava flow itself is an illustration based upon imaging data. The image on the right is a composite using a five-color observation made on Feb. 22, 2000, at 315 meters (1030 feet) per pixel.

These are among the most fortuitous observations made by Galileo because this style of volcanism is too unpredictable and short-lived to plan to photograph.

Short-lived bursts of volcanic activity on Io had been previously detected from Earth-based observations, but interpreting the style of volcanic activity from those lower-resolution views was highly speculative. These Galileo observations confirm hypotheses that the initial, intense thermal output comes from active lava fountains.

Galileo's high-resolution observations of volcanic activity on Io have also confirmed other hypotheses based on earlier, low- resolution data. These include interpretations of slowly spreading lava flows at Prometheus and Amirani and an active lava lake at Pele. These tests of earlier hypotheses increase scientists' confidence in interpreting volcanic activity seen in low-resolution remote sensing data of Earth as well as Io. However, these data are still of insufficient resolution to adequately test the more quantitative models that have been applied to volcanic eruptions on Earth and Io.

These images also show other geologic features on Io, such as the scalloped margins of the plateau to the northeast of the active lavas. These margins appear to have formed by sapping, a process usually associated with springs of water. Liquid sulfur dioxide might be the fluid responsible for sapping on Io. A better understanding of sapping on Io will influence how scientists interpret similar features on Mars (where the viability of carbon dioxide or water as the sapping fluid remains controversial).

Amirani lava flow

Amirani
Amirani's big lava flow on Io. Photo: NASA/JPL

These images from NASA's Galileo spacecraft show changes in the largest active field lava flows in the solar system, the Amirani lava flow on Jupiter's moon Io. Scientists have identified 23 distinct new flows by comparing the two images taken 134 days apart, on Oct. 11, 1999, and Feb. 22, 2000.

The Amirani lava-flow field spans more than 300 kilometers (190 miles). Individual flows within it are each several kilometers or miles long, which is about the size of the entire active eruption on Kilauea, Hawaii. In total, the new lava flows at Amirani covered about 620 square kilometers (240 square miles) of Io in less than five months. By comparison, Kilauea covered only about 10 square kilometers (4 square miles) in the same time. Amirani is huge even when compared to other Ionian lava flows: The Prometheus lava flow field covered only about 60 square kilometers (24 square miles) during this time.

Galileo scientists are studying Amirani to understand how such large lava flows are created. The last eruption this size on Earth happened about 15 million years ago along the Columbia River in what is now the state of Washington. Many scientists thought that such long lava flows were formed in violent volcanic outbursts. However, the eruption observed at Amirani is relatively calm, despite the fact that over 100 tons of lava are disgorged every second. Galileo's observations of Io indicate that huge, ancient lava flows on the Earth, such as the Columbia River flood basalts, could also have formed in relatively tranquil eruptions.

The color image on the left is a composite of black-and- white images collected on Feb. 22, 2000, at a resolution of 210 meters (690 feet) per picture element, and color images collected on June 30, 1999, at 1.3 kilometers (0.8 mile) per picture element. The white boxes and arrows show the locations of the areas analyzed in detail on the right. The left-hand pair of black-and-white images, labeled I24, are parts of a mosaic collected on Oct. 11, 1999, at 500 meters (550 yards) per picture element. The center pair of images, labeled I27, shows what the same areas looked like on Feb. 22, 2000. These later images are about twice as sharp as the earlier images, making some features that did not change appear crisper. In order to demonstrate the real changes, the I27 images were divided by the I24 images, producing the pair of ratio images on the right. The new dark lava that erupted between October 1999 and February 2000 has been highlighted in red.

The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the Galileo mission for NASA's Office of Space Science, Washington, D.C.
